Name: 60km H Road Dynamic Weighing System Full Coverage High Precision
Brand: Hengliang
Price: 20000 USD

Brand Name : Hengliang

Model Number : ZQS-40-SY

Certification : ISO

Place of Origin : Zhenghou`China

MOQ : 1 SET

Price : USD 20000-35000/SET

Payment Terms : T/T

Supply Ability : 30 SET/Month

Delivery Time : 5~7days

Packaging Details : Wooden box

Type : WIM System

Power : AC 220V

Error : 3%~10%

Speed : 0.5~100km/h

Axle load : 40Ton (single axle)

Single axle max overload : 60Ton

MTBF : ≥20000h

Temperature : -45~+80℃

Contact Now

0.5-100km/H High Precision Full Coverage Road Dynamic Weighing System

Product Description

It has the function of dynamic detection and output of vehicle model, number of axles, axle weight and total weight of the whole vehicle.
It has vehicle video recording and output functions.
It has the function of capturing and outputting vehicle images.
It has vehicle speed and flow detection and output functions.

Product Parameters

Weighing accuracy	90%~97%
Single axle load	40Ton
Single axle max Load	60Ton
Speed	0.5~100km/h；
Speed error	≤±1km/h
Wheelbase error	≤±100mm
Working voltage	AC 220V 50Hz
Output information	Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time
Maximum number of lanes	8 lanes
Data storage	It can store up to 10000 pieces of vehicle information data
data interface	RJ485
work environment	-45℃～80℃,0～95%
Confidence	≥95%

Project Case

60km / H Road Dynamic Weighing System Full Coverage High Precision
